Description
|
IP Video Input |
Up to 8 channels, up to 6 MP resolution |
|
Incoming Bandwidth |
60 Mbps |
|
Outgoing Bandwidth |
60 Mbps |
|
HDMI Output |
1 channel, up to 1920 × 1080p / 60 Hz |
|
VGA Output |
1 channel, up to 1920 × 1080p / 60 Hz |
|
Video Output Mode |
Simultaneous HDMI and VGA output |
|
Video Compression |
H.265+, H.265, H.264+, H.264 |
|
Recording Resolution |
Up to 6 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
|
Decoding Capability |
4-channel @ 1080p (30 fps), 2-channel @ 4 MP (30 fps), or 1-channel @ 6 MP (30 fps) |
|
Synchronous Playback |
4 channels |
|
Remote Connections |
16 |
|
Network Protocols |
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP |
|
Network Interface |
1 × RJ-45 10/100 Mbps self-adaptive Ethernet port |
|
PoE Ports |
8 × RJ-45 10/100 Mbps self-adaptive Ethernet ports |
|
PoE Standard |
IEEE 802.3af/at |
|
PoE Power Budget |
≤ 75 W |
|
SATA Interface |
1 × SATA |
|
Maximum HDD Capacity |
Up to 6 TB |
|
USB Ports |
2 × USB 2.0 (rear panel) |
|
Alarm Input/Output |
N/A |
|
Power Supply |
48 VDC, 1.8 A |
|
Power Consumption |
≤ 10 W (without HDD) |
|
Operating Temperature |
-10°C to +55°C (+14°F to +131°F) |
|
Operating Humidity |
10% to 90% |
|
Dimensions (W × D × H) |
265 × 223 × 48 mm (10.4 × 8.8 × 1.9 inches) |
|
Weight |
≤ 1 kg (2.2 lb) |
