Description
|
Specification |
Details |
|---|---|
|
IP Video Input |
Up to 4 channels |
|
Maximum Camera Resolution |
Up to 6 MP |
|
Incoming Bandwidth |
40 Mbps |
|
Outgoing Bandwidth |
60 Mbps |
|
Video Output |
1 × HDMI and 1 × VGA |
|
Simultaneous Output |
HDMI and VGA simultaneous output |
|
Maximum Display Resolution |
1920 × 1080p at 60 Hz |
|
Video Compression |
H.265+, H.265, H.264+, H.264 |
|
Decoding Capability |
Up to 4 channels at 1080p (30 fps) |
|
Decoding Capability |
Up to 2 channels at 4 MP (30 fps) |
|
Decoding Capability |
Up to 1 channel at 6 MP (30 fps) |
Network and PoE Specifications
|
Specification |
Details |
|---|---|
|
PoE Interfaces |
4 independent RJ-45 PoE ports |
|
PoE Port Speed |
10/100 Mbps |
|
PoE Standard |
IEEE 802.3af/at |
|
Total PoE Power Budget |
≤ 36 W |
|
Network Interface |
1 × RJ-45 Ethernet port |
|
Network Port Speed |
10/100 Mbps, self-adaptive |
|
Remote Connections |
Up to 16 |
|
Network Protocols |
TCP/IP, DHCP, HiK-Connect, and more |
Storage and Interfaces
|
Specification |
Details |
|---|---|
|
SATA Interface |
1 × SATA |
|
Maximum Hard Drive Capacity |
Up to 6 TB (single HDD) |
|
USB Ports |
2 × USB 2.0 |
|
USB Port Location |
Rear panel |
Power and Physical Specifications
|
Specification |
Details |
|---|---|
|
Power Supply |
48 VDC, 1 A |
|
Power Consumption |
≤ 10 W (without hard drive) |
|
Operating Temperature |
-10°C to +55°C (14°F to 131°F) |
|
Dimensions (W × D × H) |
265 × 223 × 48 mm |
|
Dimensions (inches) |
10.4 × 8.8 × 1.9 inches |
|
Weight |
≤ 1 kg (2.2 lbs. without hard drive) |
.
